Features to highlight
Approximate maximum working height (mts): 3.05
Inclination °: 75
Rung (mm): 30
Rung spacing (mm): 270
Other details
Four continuously adjustable base extensions (2×1,000, 2x 370)
Protection against expansion with high resistance perlon tapes.
Patented locking device with retaining studs.
Model | Rungs | Weight | Width D | Overture N | Working height B | Total height M | Folded length |
4123/2x5 | 2x5 | 12,0 | 0,505 | 0,95 | 2,27 | 1,45 | 1,47 |
4123/2x6 | 2x6 | 12,8 | 0,535 | 1,15 | 2,50 | 1,703 | 1,75 |
4123/2x7 | 2x7 | 13,8 | 0,565 | 1,25 | 2,80 | 1,95 | 2,05 |
4123/2x8 | 2x8 | 15,0 | 0,595 | 1,45 | 3,05 | 2,25 | 2,35 |
