Features to highlight
Approximate maximum working height (mts): 6
Inclination °: 75
Rung (mm): 30
Rung spacing (mm): 270
Other details
Ergonomic extruded side pillars.
30 mm opening tape.
First step reinforcement braces.
Angled feet that offer more support surface.
Model | Rungs | Weight | Width D | Overture N | Working height B | Total height M | Folded length |
6023/2x5 | 2x5 | 5,8 | 0,51 | 1,00 | 2,32 | 1,50 | 1,57 |
6023/2x6 | 2x6 | 6,8 | 0,54 | 1,15 | 2,59 | 1,75 | 1,85 |
6023/2x7 | 2x7 | 7,8 | 0,57 | 1,30 | 2,86 | 2,00 | 2,13 |
6023/2x8 | 2x8 | 9,2 | 0,60 | 1,45 | 3,13 | 2,30 | 2,40 |
6023/2x9 | 2x9 | 10,3 | 0,63 | 1,60 | 3,40 | 2,55 | 2,69 |
6023/2x10 | 2x10 | 11,4 | 0,66 | 1,85 | 3,67 | 2,65 | 2,95 |
6023/2x12 | 2x12 | 14,1 | 0,72 | 2,05 | 4,21 | 3,40 | 3,53 |
6023/2x14 | 2x14 | 18,8 | 0,78 | 2,40 | 4,75 | 3,90 | 4,10 |
6023/2x16 | 2x16 | 22,5 | 0,84 | 2,60 | 5,29 | 4,45 | 4,65 |
